SWR Pipes & Fittings

The System

The SWR Drainage System is the result of SFMC Group research. It was the first such uPVC system in India which successfully replaced conventional CI and AC products. This system enables fast and efficient removal of waste without blockage and leakage. Its high impact strength, chemical and corrosion resistance, long life and virtually zero maintenance explain why it continues to be the preferred brand of architects and builders every where. .

Technical Specifications

SFMC Manufacturers Plain and Socket end Pipes with nominal Out side Diameter from 75, 90, 110 & 160 mm. These Pipes are used in soil and waste discharge system inside the building including ventilating and rain water applications.

High quality standards and wide range

Pipes and fittings are available in 40mm to 160 mm. Pipes conforms to IS 13592:92 and fittings conforms to IS 14735:99 and are made to international standards. Unique click ring type fittings are most suitable to be used in combination with Type B pipes for high-rise buildings. The system consists of pipes and wide range of fittings with various traps, which makes the system complete in all respect and hence customer need not to depend on conventional system

Stronger and Long Lasting

This system is highly resilient, tough and durable with high tensile strength and high impact strength. Moreover it is free from problems caused by scale formation, rusting, weathering and chemical action, and hence lasts for lifetime.

Excellent chemical and corrosion resistance

Being non-metallic, this system is completely free from corrosion and offers very good resistance to wide range of chemicals.

UV resistance

which eliminates the adverse effect of sunlight and weather and can therefore be safely used for outdoor installations.

Quick and convenient installation

Being extremely light in weight and provided with special rubber jointing technique, installation of this system becomes much easier.

Quick and efficient removal of waste without leakage

Superior flow characteristics are ensured by the mirror smooth, restriction free inner surface of pipes and fittings, thus the system is free from problems of clogging and drain choke-up. System is completely leak-proof and designed to maintain high standards of hygiene.

Adequate and easy access for cleaning and clearing obstructions.

Least maintenance

Once installed Supreme S.W.R. drainage system needs no maintenance.

Cost Effective

Supreme S.W.R. drainage system is more cost effective than any conventional drainage system.

Waste discharge system in residences, commercial complexes, resorts, hospitals, academic institute
An ideal replacement for CI and GI piping
Venting of gases and odours in domestic plumbing
Non-pressure industrial drainage application (based on chemical compatibility)
Rain water transportation and harvesting for residential & commercial buildings.

Specifications

Fittings

Pipes

Material

Unplasticized Polyvinyl Chloride (UPVC)

Colour

Light Grey

Refernce Standards

IS 14735 : 1999

IS 13592 : 2013

Working pressure (kg/cm2)

Non Pressure Application

End Connections

Rubber Ring & Solvent Joint

Variants

–

Type ‘A’ & Type ‘B’
